Boetmann Solar Submersible / Borehole Pump with Control Box – 500W – 120m

Boetmann Solar Submersible / Borehole Pump with Control Box - 500W - 120m

Features:

• Permanent magnet, brush-less motor for optimal energy efficiency
• NSK bearing with alloy mechanical seal for enhanced durability
• Intelligent water shortage protection to prevent damage
• MPPT function for maximum solar energy utilization
• Automatic Stop/Start for ease of use
• Soft start protection to extend the life of the pump
• Over current protection for safety
• Max Water Submersion Depth: 50m
• Pump Isolation: IP68 (fully waterproof)
• Motor Speed: 500 - 4000rpm
• Discharge size: 20mm
• Power: 500W
• Voltage: 48V DC
• VOC Max: 96V DC

Specifications:

• Max Flow: 1600L/h
• Max Head: 110m
• Water Delivery Capacity at Varying Head Heights:
  • 0m - 1600L/h
  • 30m - 1500L/h
  • 60m - 1250L/h
  • 75m - 1000L/h
  • 90m - 750L/h
  • 105m - 500L/h
  • 110m - 250L/h

What's in the box:

• 1 x 500W Solar Pump
• 1 x Control Box
• 1 x Spare Rotor
• 2 x Floats
• 1 x Waterproof Tape
• 1 x Insulation Tape
• 1 x Instruction Manual

The Boetmann Solar Submersible / Borehole Pump with Control Box - 500W - 120m is the ideal solution for efficient, off-grid water pumping. Designed with permanent magnet, brush-less motor technology, this pump ensures superior energy efficiency and long-lasting performance, making it perfect for use in remote or arid areas where power supply is limited or unreliable.

With a maximum flow rate of 1600L/h and a maximum head of 110m, this powerful pump is designed to handle a variety of water pumping applications, including agricultural irrigation, livestock watering, and general water distribution. Whether you're located in a rural area or on a property without a reliable electricity supply, this solar-powered pump provides a cost-effective and sustainable solution for your water needs.

The MPPT (Maximum Power Point Tracking) function maximizes the utilization of solar energy, ensuring that the pump operates efficiently even under varying sunlight conditions. The pump is also equipped with intelligent water shortage protection, preventing damage to the motor if there is insufficient water supply. Overcurrent protection and soft start protection add additional layers of safety, ensuring smooth operation and protecting the pump from potential issues.

The pump is IP68-rated, meaning it is fully waterproof and suitable for submersion depths of up to 50m. With a motor speed range of 500 - 4000rpm, the pump can adapt to varying flow requirements.
